Westbourne Seat

Westbourne Seat

A comfortable heavy duty seat, with very substantial boards, particularly suitable for landscape schemes in a wide variety of environments.

The boards are secured from the rear by stainless steel pin-in-socket fastenings, which go through the frames into timber inserts in the boards. These fastenings are secure and discreet.

  • Boards available in iroko or seasoned oak
  • Supplied with extended legs (for concreting in), as standard.
  • Also available with pedestal base legs (for bolting down), or ground anchoring version
  • Pedestal base option can be bolted down with K1 rawl bolts, K4 extended rawl bolts, or K12 extended rawl bolts
  • Frames in either Acrylic Coating or Street-Tough finish in black as standard
  • Supplied with seat assembled, with legs to bolt on
Westbourne Seat
  • Middle boards 45 x 70mm finished
  • Front boards 70 x 70mm finished
  • Top boards 70 x 70mm finished
  • Legs 76 x 3mm circular hollow
  • Cradle-frames 12 x 80mm flat
  • Length 1800mm
  • Weight approx. 81kg.

Boards available in iroko or seasoned oak

If you'd like more information please fill in the form at the bottom of this page, call us on: 01639 845394 or click here to email us.

All hollow section seats in this range have:

  • Fully welded steel end caps, as opposed to plastic end plugs
  • Stainless steel tamper resistant fastenings
  • Boards fully finished and coated
  • Standardised parts for ease of replacement
  • Various ground fixing options
  • Two standard lengths available, 1800mm and 2400mm
  • Optional arms available
Fully welded end caps
Concealed nut fastening
Tamper resistant fastenings
Concealed nuts

This fixing system has several important advantages:

  • A special key is needed to undo these fastenings, which reduces the risk of unauthorised dismantling
  • No nuts are visible at the rear of the frames, and the fastenings are flush fiing on the board surface
  • Stainless steel fastenings don’t rust, so look good indefinitely
  • The replacement of individual boards is a straight forward task, even many years later

These seats are frequently specified for commemorative purposes for which several types of plaque are available for more information please visit the Commemorative Inscription Service page.
